0.5A Cts Potentiometer 500k Potentiometer With Switch DC 500V

Product Categories

Dongguan Tianqian Electronics Co., Ltd.

Contact Now

0.5A Cts Potentiometer 500k Potentiometer With Switch DC 500V

Brand Name : TQ

Model Number : R1610S

Certification : CE

Place of Origin : China

MOQ : 1000

Price : 2.3

Payment Terms : T/T

Supply Ability : 50000 per day

Delivery Time : 15 work day

Packaging Details : carton

torque : section 4 ±1.5kg

rated power : DC 30V 0.5A

contact resistance : 25mΩ Max.

insulation resistance : DC 500V 100mΩ Min.

withstand voltage : 500V

Contact Now

Product Description

Specification

0.5A Cts Potentiometer 500k Potentiometer With Switch DC 500V

item	value
Certification	Rohs CE
Whether the smart	No
Place of Origin	China
	Guangdong
Brand Name	TQ
Model Number	R1610S
Max. Current	0.5A
Max. Voltage	500V DC
Mechanical Life	10000 Cycles
torque	section2 ±1kg
rated power	DC 30V 0.5A
Contact resistance	25mΩ Max.
InsulatIon resistance	DC 500 V 100mΩ Min.
withstand voltage	500V

Packing & Delivery

Carton with blister box inside

Company Profile

00:01

02:Dongguan TianQian Electronics Co., Ltd. established in 2008, it is specialized in design, development and production of high precision components such as Rotary Potentiometer, Sliding Potentiometer, Foot Switch, Band Switch, AC Switch, Sensor, Encoder, Tact Switch and Connectors. The products are widely used in Dimmable Lighting, Audio Mixer, Home Appliances, Automobile, Multimedia, Audio Equipments, Instrument, Toys, Aviation Model and Communication Equipments. We have an area of 3,000 square meters of factory building. Our R&D team members have more than 20 years experience in the component industry. In order to meet the high quality demand from worldwide customers, we widely use automated production lines which can output more than 80% of annual production capacity. It takes pride in the achievement that we have been the key supplier of JVC, Brother, IKEA, Midea, Microsoft, Honeywell, Sennheiser, Primax and GGEC...etc. With the consistent enterprise principles "Striving Excellence" & "Quality Assurance", we hope both parties can establish a mutual

FAQ

1.The rotary operating force (rotation or sliding) of the potentiometer will become lighter as the temperature increases, and become tighter as the temperature decreases. If the potentiometer is used in a low temperature environment, it needs to be explained so that special low temperature resistant grease can be used.
2.. The shaft or sliding handle of the potentiometer should be designed as short as possible. The shorter the shaft or slider, the better and more stable the handle. On the contrary, the longer the shaking is, the bigger the hand feel will change.
3.. The power of the carbon film of the potentiometer can withstand the surrounding temperature of 70 °C, and its power may be lost when the operating temperature is higher than 70 °C.
